Material: Solid Surface
Customization:
Customization options:
| Product / Model No. | OE006 |
|---|---|
| Material | Cast solid-surface (acrylic + mineral fillers), solid through-body |
| Standard Size (L×W×H) | 1690 x 780 x 880mm; OEM size on request |
| Net Weight | 150KG |
| Finish & Color | Matte (standard) / Gloss; pure white as standard — custom color available |
| Drain & Overflow | Center or end drain; flexible hose Ø40/50; overflow optional; position OEM |
| Installation | Freestanding |
| MOQ | 5 pcs / order; 1 pc sample supported; branding & packaging MOQ 10 pcs |
| Lead Time | Sample 5–7 days; mass 10–15 days (peak 15–25 days) after deposit |
| Monthly Capacity | ≈300 pcs / month (single shift) |
| Certifications | ISO 9001 factory; CE/SGS test reports (material & 100% water/leak test records) |
| Warranty | 5-year tub body |
| Quality Control | Visual & dimension check; finish inspection; batch color tolerance; 100% water/leak test |
| Packaging | EPE foam wrap + PE bag + heavy carton; ISPM-15 fumigated wooden crate |
| HS Code | 3922.10 — Baths of plastics (solid-surface/acrylic) |
| Project Support | CAD/DWG & 3D STEP/OBJ; installation & care guides; pre-shipment photo/video |
| Origin / Brand | Yunfu, China — Opaly |
| Test items | Test methods | Test results |
|---|---|---|
| Water absorption / Apparent density | EN 14617-1:2005 | 0.09% (Classification: W3) 1740 kg/m³ |
| Chemical resistance | EN 14617-10:2012 | Classification: C4 |
| Flexural strength (natural condition) | EN 14617-2:2008 | 43.4 MPa (Classification: F4) |
| Impact resistance | EN 14617-9:2005 | 4.97 J |
| Thermal shock resistance | EN 14617-6:2012 | Mass loss: 0.20% Flexural strength after thermal shock: 56.9 MPa Flexural strength loss: -31.1% |
| Abrasion resistance | EN 14617-4:2012 Agglomerated stone — Test methods — Part 4 |
22.2 mm |
| Linear thermal expansion coefficient | EN 14617-11:2005 Agglomerated stone — Test methods — Part 11 |
48.7 × 10−6 / °C |
| Slip resistance | EN 14231:2003 | Dry: 74; Wet: 44 |
| Dimensions, geometric characteristics and surface quality | EN 14617-16:2005 | Tolerance: see clause 6 Surface quality: No defects |
Environmental
Solid
Excellent insulation
Easy to repair
Easy clean
Cast in true solid-surface (acrylic + mineral), this tub is solid through-body—not a thin acrylic/fiberglass shell. The dense, non-porous core keeps water warmer for longer, dampens noise, and delivers a reassuring stone-like feel. The surface is renewable: light scratches can be sanded and restored on site for long service life in hospitality and residential builds.
Less Durability
Poor Insulation
Noise Concerns
Maintenance Challenges
Limited Longevity
Solid through-body, warm to the touch, excellent heat retention, non-porous & hygienic, low noise, and on-site refinishable for long service life in hospitality and premium residential projects.
5-star hotel guest suites — freestanding centerpiece for premium ensuites
Presidential / VIP suites — window-side soaking with panoramic view
Boutique resort villas — private spa-style bathrooms with statement tub
Spa & wellness hydrotherapy rooms — hygienic, non-porous surface; warm touch
Couples’ spa suites — double-ended 1700–1800 mm for two-person soaking
Luxury residential master suites — stone-like feel, quiet, heat-retentive
Penthouses & sky villas — gallery-style bath as focal art piece
Show flats & design galleries — developer model rooms, brand showcases
Serviced apartments (premium tier) — durable, easy to maintain for high turnover
Private members’ clubs & wellness lounges — calm, noise-dampened soaking
Yacht / superyacht bathrooms — repairable, solid feel with controlled weight
Luxury ski chalets & mountain lodges — superior heat retention in cold climates
High-end senior living & recovery suites — hygienic, easy-clean matte surface
Designer boutique hotels — compact 1500–1600 mm options for urban layouts
| Item | Standard Data |
|---|---|
| MOQ | 5 pcs; sample orders supported |
| Daily Capacity | 10 pcs / day |
| Monthly Capacity | 300 pcs / month |
| Standard Lead Time | 7 days ex-factory after deposit (peak season: 7–20 days) |
| Stable Model Statement | This model is in long-term stable production. |
| Batch Color Variation | There may be unavoidable slight color variations between different batches under the same light source. Photos or videos of each batch will be provided for your confirmation before shipment. |
| Step | Operation | Notes / Materials |
|---|---|---|
| 01 | QC check & clean | Confirm model/finish; wipe dust. |
| 02 | Foam wrap | 5–10 mm EPE + corner guards; tape seams. |
| 03 | Bag & desiccant | PE inner bag; add desiccant; accessories in small box. |
| 04 | Outer carton | Heavy-duty box; add cushioning; seal with packing tape. |
| 05 | Wooden crate & strapping | ISPM-15 crate; PET straps + stretch wrap; apply shipping marks. |
*All wood used in our quartz slab packaging (pallets, crates, battens) is fumigated to ISPM 15 standards before shipment. This prevents pest contamination and ensures smooth customs clearance. Fumigation marks and certificates are available on request.
We have 8 production lines for quartz stone and 6 for acrylic solid surface, as well as 3 fully automated production lines for sanitary ware, equipped with advanced robotic polishing. This enables us to complete and deliver your orders within 20 days in most cases.
Enjoy superior quality direct from our factory—no inflated distributor costs. Trusted by Contractors and import buyers in over 40 countries, we maintain an 85% client re-order rate.
Every stage of the production process, from raw materials to finished products, is strictly monitored, and each product undergoes individual inspection by our quality control department. We confidently offer a 5-year quality guarantee for every product, along with lifelong online technical support.
For freestanding solid-surface (acrylic) bathtubs. O1 = floor waste/outlet. Professional installation recommended.
Refer to the product drawing for exact rough-in dimensions. Keep access for future service.
With 2–4 people and lifting straps/suction cups, lift vertically off the pallet. Do not drag the rim.
Place the tub near its final position and align the drain over O1.
Dry-fit only (no sealant yet). Check level front–back and side–side; mark the final footprint on the floor.
Raise the tub slightly; clean and dry the marked area.
Run a continuous 3–5 mm bead of neutral-cure sanitary silicone around the footprint (full perimeter as shown).
If positioning pads are supplied, place them first, then apply sealant.
Lower the tub straight down into its marks; press evenly and wipe off squeeze-out.
Install the waste/overflow kit in the order shown: flange → gasket(s) → locknut.
Apply a thin bead of neutral silicone under the flange; tighten hand-tight + ¼ turn (do not over-torque).
Connect the flexible waste hose and secure the clamp; keep access for future service.
Leak test: fill the tub, operate the waste, and check all joints for drips.
Join the flexible hose to O1; clamp firmly. Keep a smooth gentle curve—no kinks, twists, or deep U-loops (see icon).
Ensure proper fall/slope to O1 and a reliable water seal to prevent odors.
Perform a second fill-and-drain test; clean the area.
Allow silicone to cure 24 h before use. Do not screw or bolt through the tub body—silicone is the primary fixing.
Daily care
Rinse after use and wipe dry with a microfiber cloth.
Use a pH-neutral, non-abrasive cleaner and a soft sponge.
Weekly clean
Remove soap scum/limescale with 1:1 white vinegar : water. Rinse and dry.
Stain removal
Light stains: cream cleanser or baking-soda paste, soft white pad.
Hair dye/makeup/oils: rinse immediately; wash with mild dish soap.
Limescale rings: vinegar/citric solution 5–10 min max, then rinse—don’t leave overnight.
Scratch refresh (renewable surface)
Matte: wet-sand 800 → 1200 → 1500 grit in small circles; finish with a white Scotch-Brite.
Gloss: wet-sand 1200 → 2000 grit, then use polishing compound and a soft pad.
Deep gouges: contact service.
Disinfection
70% isopropyl alcohol wipe, or bleach 1:10 for ≤5 min. Rinse thoroughly.
Heat & impact
Don’t pour boiling water directly—mix with cold first.
Don’t stand or sit on the rim; avoid dropping heavy objects.
Chemicals to avoid
Acetone, paint/lacquer thinners, strong acids/alkalis (pH <4 or >10), abrasive powders, steel wool.
Sealant & drain
Inspect the silicone bead around the base every 6–12 months; re-seal if cracked.
Clean the waste/overflow and hair strainer regularly; check for leaks annually.
Hard-water tip
Squeegee after each use; a softener reduces scale buildup.
A composite of acrylic/polyester resins and mineral fillers; dense, stone-like, and non-porous.
Typical freestanding units weigh ~90–180 kg (200–400 lb); many models list ~250–280 lb—check floor capacity or consult an engineer.
Yes—solid walls provide good insulation and keep water warm longer.
Yes—surfaces are non-porous, easy to clean, and resist mildew when maintained properly.
Use pH-neutral, non-abrasive cleaners; for soap scum/limescale, mild vinegar solution, rinse and dry.
Light marks usually sand/polish out with fine grits (≈800–1200 then up to 2000); deeper chips may need filler and pro refinishing.
Connect a flexible drain to the floor outlet, run a neutral-cure silicone bead around the base, leak-test, and allow ~24 h to cure.
Avoid dumping boiling water directly and harsh solvents/strong acids/alkalis; dissolve bath salts/oils fully and rinse.
Yes—freestanding tubs just need a drain plus hot/cold supplies; rough-in per drawing and local code.
Multiple shapes and mounting options (freestanding, drop-in, etc.) across compact to large sizes; OEM/ODM feasible.
